Baguette line Mecatherm

515102
Baguette line Mecatherm
M/C: Baguette & bun roll line
Group: bread line equipment
Producer: Mecatherm Megaline
Control: Fully automatic
Delivery: On request
Terms of delivery: From Location:
Location: Germany
Condition: Used

Technical Data:
Baguette Line without Mixersystem and Divider
Manufacturer: Mecatherm
Year of construction: 2005
Output: 6000 baguette / h
30000 baguette rolls / h
Baking tray format: 2000 x 800 mm
Total connection: 264 kVA; 400 V - 50 Hz T + N
System consisting of:

1. Dough spreader
Manufacturer: Mecatherm

2. Conveyor belt 1 on the left
Working width: 600 mm

3. Conveyor belt 2 on the right
Working width: 600 mm

4. Baguette preformer 1 on the left
Working width: 600 mm

5. Baguette preformer 2 on the right
Working width: 600 mm

6. Mecatherm block 1 on the left
Working width: 600 to 800 mm

7. Mecatherm block 2 on the right
Working width: 600 to 800 mm

8. Baking tray infeed station 1 on the left
Baking tray format: 2000 x 800 mm

9. Baking tray infeed station 2 on the right
Baking tray format: 2000 x 800 mm

10. Lowering belt 1 on the left
Working width: 820 mm

11. Lowering belt 2 on the right
Working width: 820 mm

12. Baking tray chain transport 1 left
Working width: 820 mm

13. Baking tray chain transport 1 right
Working width: 820 mm

14. Baking tray transfer station proofing room
Working width: 2000 mm

15. Baking tray buffer station MPI
Working width: 2000 mm

16. Final fermentation tunnel elevator system
Manufacturer: Mecatherm
Type: EMPII-E 64-07-120
Steam pressure: 0.3 bar
Requirement: 2x20 = 40 kg / h
Glycol water
Throughput: 2x5 = 10m³ / h
max pressure: 3 bar
Inlet temperature: + 6 ° C
Outlet temperature: + 12C

17. Cutting station
Manufacturer: Mecatherm
Typ: MPII

18. Oven Elevator system
Manufacturer: Mecatherm
Typ: FMPI 28-03-150
6 Gas burner
Connected load: 1050000 kCal/h
Gas pressure on burner: 100 - 300 mbar
Fresh air supply 250 m³/h pro burner = 1500m³/h
Steam pressure: 0.2 - 0.3 bar
Requirement: 100 kg/h

19. Indoor air cooler
Manufacturer: Mecatherm
Type: RMPII 48-02-150

20. Blast Freezer Elevator System
Manufacturer: Mecatherm
Type: SMPII 48-04-150
Connected load: 320,000 kcal / h
Refrigerant CO2
Total volume of the evaporator: 1560 liters
Max working pressure: 50 bar

21. Baking tray return station
Working width: 2000 mm

22. Product take-off station
Working width: 800 mm

23. Inclined conveyor to the Vertkalen packaging machine
Working width: 500 mm

24. Multihead weigher with platform
Manufacturer: MultiWeigh
Type: HDW 10-8.0-50 kg
Year of construction: 2006
Execution: stainless steel

25. Vertical packing machine
2 pieces
Manufacturer: Wolf
Type: VPP 450
Year of construction: 2006

26. Metal detector
Manufacturer: Mettler Toledo Safeline
Passage: 500 x 300 mm
Connection: 330 W; 100-240 VAC ~

27. Cartoner
Manufacturer: Knecht
Type: BK07
Year of construction: 2006
Connection: 11.68kW- 400V; 50 Hz; 26.8 amps

28: carton sealer
including driven roller conveyor
Manufacturer: Knecht
Type: BK 3000
Year of construction: 2005
Connection. 3.48 kW; 400V; 50 Hz; 8.01 amps

29. Continuous weigher
Manufacturer: Mettler Toledo
Inspection, dismantling, transport and assembly with commissioning on request
